Pneumatic Air Cylinder
- Double Acting - 160mm Bore x 175mm Stroke - Pull Rod Type - SC
Product Video
General Description
Pneumatic Air Cylinder - Double Acting – 160mm Bore x 175mm Stroke - Pull Rod Type – SC
This standard double action SC air piston is a pull rod type. The bore is 160mm and the stroke is 175mm. It offers an adjustable buffer and is made from the highest professional-grade materials.
Function
The pneumatic air cylinders use compressed air acting on a piston inside a cylinder to move a load along a linear path. The double acting pistons have two separate ports to extend and retract the piston.
Applications
Air pistons are types of cylinders utilized in a variety of industrial sectors, factory automation and packaging, as well as transportation and life science applications.
Technical Details
| Certifications: | ISO |
|---|---|
| Size: | 46.6x18x18 cm |
| Motion Pattern: | Double Action |
| Working Medium: | Air |
| Operating Voltage Range: | 1.0-9.0 V |
| Ensured Pressure Resistance: | 13.5kgf/cm? |
| Operating temperature Range: | -5 - 70°C |
| Operating Speed Range: | 30- 800mm/s |
| Buffer Type: | Adjustable Buffer |
| Buffer Stroke: | 32 |
| Port Size: | G3/4" |
| Stroke Size: | 175 mm |
| Bore size: | 160 mm |
| Material: | Aluminum Alloy |
| Max Air Pressure: | 8 kg/cm |
| Brand: | Deelat Industrial |
Do you have a question about this product?
Portable Ventilation Fan - Diameter 300 mm - Single Phase - 110V The vent fan has a diameter of 300 mm, is single phase, and the voltage is 110V. It has an air volume of 65 cubic meters/min, and its max RPM rating is 3300 RPMs. Function The...
Pneumatic Air Cylinder – Double Acting – 80mm Bore x 25mm Stroke – Pull Rod Type – SC This standard double action SC air piston is a pull rod type. The bore is 80mm and the stroke is 25mm. It offers an adjustable buffer and is made from the...
Pneumatic Air Cylinder – Double Acting – 63mm Bore x 175mm Stroke – Pull Rod Type – SC This standard double action SC air piston is a pull rod type. The bore is 63mm and the stroke is 175mm. It offers an adjustable buffer and is made from the...
PVC Flexible Duct – 610mm (Diameter) * 4.57M (Length) The 610 mm in diameter PVC duct has a length of 4.57M and is made out of a PVC material. It is able to endure temperatures between -20°C and +80°C. It is built with a steel wire helix frame....
Pneumatic Air Cylinder – Double Acting – 25mm Bore x 250mm Stroke – Mini – MA This standard double action MA air piston is a mini type. The bore is 25mm and the stroke is 250mm. Like all of Deelat’s types of cylinders, it is made from the...
Pneumatic Air Cylinder – Double Acting – 63mm Bore x 700mm Stroke – Pull Rod Type – SI This standard double action SI air piston is a pull rod type. The bore is 63mm and the stroke is 700mm. Like all of Deelat’s types of cylinders, it is made...
Pneumatic Air Cylinder - Double Acting – 160mm Bore x 175mm Stroke - Pull Rod Type – SC This standard double action SC air piston is a pull rod type. The bore is 160mm and the stroke is 175mm. It offers an adjustable buffer and is made from the...
Pneumatic Air Cylinder – Double Acting – 50mm Bore x 250mm Stroke – Pull Rod Type – SI This standard double action SI air piston is a pull rod type. The bore is 50mm and the stroke is 250mm. Like all of Deelat’s types of cylinders, it is made...
Pneumatic Air Cylinder – Double Acting – 80mm Bore x 300mm Stroke – Pull Rod Type – DNC This standard double action DNC air piston is a pull rod type. The bore is 80mm and the stroke is 300mm. Like all of Deelat’s types of cylinders, it is made...
Pneumatic Air Cylinder – Double Acting – 200mm Bore x 125mm Stroke – Pull Rod Type – SC This standard double action SC air piston is a pull rod type. The bore is 200mm and the stroke is 125mm. It offers an adjustable buffer and is made from the...
Pneumatic Air Cylinder – Double Acting – 40mm Bore x 100mm Stroke – Pull Rod Type – SI This standard double action SI air piston is a pull rod type. The bore is 40mm and the stroke is 100mm. Like all of Deelat’s types of cylinders, it is made...
Pneumatic Air Cylinder – Double Acting – 63mm Bore x 125mm Stroke – Pull Rod Type – SC This standard double action SC air piston is a pull rod type. The bore is 63mm and the stroke is 125mm. It offers an adjustable buffer and is made from the...
Does this Pneumatic Air cylinder come with a double action control function?
Will you provide single piece
Hello Ravi, thank you for your question. If you are asking if we would sell just 1pneumatic cylinder the answer is yes. There is no minimum order quantity when purchasing a pneumatic cylinder from Deelat Industrial. You can buy 1 or 100, however, the more cylinders you purchase the better pricing you will get.
Hi it the barrel for this cylinder available to purchase seperate or does it only come as a complete cylinder.
Hello Trevor, thank you for your question. If you purchase this Pneumatic Cylinder you will receive exactly what you see in the photo. We do not sell include anything other than what you see photographed and on the product video.
I am looking for just Pneumatic cylinder end caps. Can i get them without the whole pneumatic cylinder?
Hi Kiran, thank you for your question. Unfortunately we do not sell pneumatic cylinder end caps by themselves.
What is the diameter of the cylinder rod?
Hi, Tony. The diameter of the cylinder rod is M16x1.5.
